Blow / Casting Low Temperature High Barrier Thermoforming Film For Food Packaging

Place of Origin China
Brand Name Hawking
Certification ISO 9001
Model Number HK-HBF001
Minimum Order Quantity 1 Ton
Packaging Details 18 Per Pallet
Delivery Time 4 Weeks
Payment Terms T/T, L/C
Supply Ability 25 Tons Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Price Negotiable Material Blow / Casting
Color Primary Colour Application Food Grade
Structure 11 Layers Product Thermoforming Film
Advantage Low Temperature Packaging Usage For Bacon Packaging
High Light

Blow High Barrier Thermoforming Film


Thermoforming Film Food Packaging

Leave a Message
Product Description

Blow / Casting Low Temperature High Barrier Thermoforming Film For For Packaging



Data Sheet:


    Unit HKCE9860 HKCE9880 HKCE98100 HKCE98125
Thickness   um 60 80 100 125
Tensile MD Mpa ≥ 34 ≥ 36 ≥ 38 ≥ 43
Strength TD Mpa ≥ 32 ≥ 35 ≥ 37 ≥ 41
Elongation MD % ≥ 420 ≥ 460 ≥ 460 ≥ 480
  TD % ≥ 435 ≥ 470 ≥ 470 ≥ 530
Transparence   % ≥ 92 ≥ 92 ≥ 92 ≥ 90
Haze   % ≤ 14 ≤ 14 ≤ 15 ≤ 18
Coefficient of Friction     0.1~0.25
WTR   g/ m2.24h. atm ≤ 8 ≤ 6 ≤ 6 ≤ 5
(38° C, 90%RH)
OTR   cc/ m2.24h. atm ≤ 5 ≤ 5 ≤ 3 ≤ 1
(23° C0%RH)
Heat Seat Strength   N/15mm ≥ 27 ≥ 29 ≥ 33 ≥ 38



EVOH film:


EVOH has always been the most widely used high barrier material. In addition to the non stretching type, the film type of this material also includes biaxial stretching type, aluminum evaporation type, adhesive coating type, etc. Among the biaxial stretching type, there are heat-resistant types for aseptic packaging products.


In the packaging field, EVOH is made into a composite film intermediate barrier layer, which is used in all hard and soft packaging.

1. High barrier: different plastic materials have different barrier properties. The co extruded film can co extrude plastics with different functions into a film to achieve high barrier effect on oxygen, water, carbon dioxide, smell, etc.


2. Strong functions: oil resistance, moisture resistance, high temperature cooking resistance, low temperature freezing resistance, quality assurance, freshness preservation and odor preservation.


3. High cost: for glass packaging, aluminum foil packaging and other plastic packaging, to achieve the same barrier effect, co extruded film has greater advantages in cost. Due to the simple process, the cost of the film products can be reduced by 20% - 30% compared with the dry composite film and other composite films.



Features :


One side smooth, one side textured. Special textured surface, easily channels the air out of the bag and away from your food, clear side helps you identify your food.


·  Save, convenient, follow food safety guidelines, FBG & FDA approved food grade, non-toxic plastic, BPA Free. Can be Microwaved (pls open the bag before put into a microwave), frozen, washed, boiled.


·  Suitable for most of the home style vacuum machines, these textured vacuum bags are able to withstand constant temperature up to 100° C for hours, they are also very suitable for sous vide applications.



Blowing film (Blow Membrane) is a plastic processing method, which refers to a plastic processing process in which plastic particles are heated and melted and then blown into a film. Usually, the polymer is extruded into a tubular film blank. In the state, the tube film is blown to the required thickness by high-pressure air, and becomes a film after cooling and shaping.


Most PEs are used for blown film processing, general low density PE (LDPE) or linear low density PE (LLDPE) are available. HDPE film grades are generally used where superior stretchability and excellent barrier properties are required. For example, HDPE films are commonly used used in merchandise bags, grocery bags and food packaging. PE film processing generally uses ordinary blown film processing or flat extrusion processing.



The main advantages of blown film are:


1. The whole film is formed in one unit production;


2. The width and thickness of the film can be effectively adjusted;


3. The extrusion temperature is uniform, which avoids the unstable quality of the film edge;


4. It can be stretched in both directions, and the mechanical properties of the obtained film are uniform;


5. It can be used to manufacture co-extruded multilayer films.



Company information:


Company name Hubei Hawking packaging material Co., Ltd
Head office DaYe district,HuangShi ctity,HuBei province,China
Branch office Bai Yun district,GuangZhou city.GuangDong province,China
Fty area 67,000 square metter with US$3.5 million and million investment
Factory scale 100-200 persons ,automatic production
Main product PA/PE,EVOH,PP,and PET composited Film with vacuum pouches
Main market North and South American ,Europe ,Australia and Asia
Certification ISO9001,ISO 14001,QS ,PAD,SGS,ROHS certificated
Production capacity 500 Ton/Month
MOQ 2 Ton-5Ton
Payment item 30% TT advance ,70% before shipment
Export port ShangHai Port
Website ,
Contact person Miss En
Contact En.Lu (





1. Q: Can I customize according to my requirements?

A: Of course, we are a professional manufacturer of plastic packaging bags with 10 years of customization experience.

2. Q: How Is The MOQ?
A: The regular MOQ is 1-2 Tons


3. Q: How Can I Get The Samples ?
A:  1) You Can Send Inquir To Us In Make In China.
      2) You can also contact us directly at 0086-134-5087-1796(WeChat/Whatsapp/Mob)

4. Q: How Do I Choose The Kind Of Package Is Right For Me
A: We have more than 3,000 OEM experience, you only need to tell us your specific requirements and uses, we will give you a quality solution.



Samples can be provided for testing, but the MOQ for formal orders is 1-2 tons.

If you are interested in it, please feel free to contact me, tell me your needs, I will send you more product details, and I can quote you a good price. My contact details are below, and I would be gald to hear from you.


Contact Person:En


Wechat/Whatsapp/Tel:+86 13450871796



Contact Person: En




Tel/Wechat/Whatsapp: +86 13450871796





Type:  Blow / Casting

Advantage:  High Barrier

Appliction: Low Temperature Thermoforming Film

Usage: For Bacon Packaging
