120um Polyester Base Plastic Films In Food Packaging Primary Coextruded

Place of Origin China
Brand Name Hawking
Certification ISO 9001
Model Number HK-PBF0015
Minimum Order Quantity 1 Ton
Packaging Details 18 Per Pallet
Delivery Time 4 Weeks
Payment Terms T/T, L/C
Supply Ability 25 Tons Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Price Negotiable Length 306 M
Width 603 Mm Thickness 120 Um
Application For Food Color Primary Colour
Texture Plastic Certificate SGS
Type Polyester Base Film Craft Coextruded
Material Plastic
High Light

120um Polyester Base Plastic Films

,

Food Packaging Polyester Base Plastic Films

Leave a Message
Product Description

Polyester Base Plastic Films In Food Packaging Primary Coextruded





Type/Structure:



*7 layers dis-symmetric PA/PE film----PA/TIE/PE/TIE/PA/TIE/PE



*7 layers symmetric PE/PA/PE film----PE/PE/PE/TIE/PA/PIE/PE



*7 layers symmetric PE/EVOH/PE film----PE/PE/TIE/EVOH/TIE/TIE/PE



*7 layers symmetric PA/EVOH/PE film----PA/TIE/PA/EVOH/TIE/PE/PE



*9 layers dis-symmetric PA/PE film---PA/TIE/PE/TIE/PA/PA/EVOH/TIE/PE



*9 layers symmetric PA/EVOH film---PE/PE/PE/TIE/PA/EVOH/PA/TIE/PE





Product Performance:



Highly puncture-resistant and flexible;



Highly transparent and high planeness of bags made by it;



Can be boiled and frozen, made into sacks with tube membrane directly;



Thickness range: 30-200um.



Thermoforming Film,Also Called Forming Film And Non-Forming Film. Used On High Speed Fls Thermoforming Film Machine, After Forming Bottom Web To Make A Chamber For Food,The Vacuum And Seal Top Web.




Product Description:



Normally Same Materials For Top Web And Bottom Web, To Achieve Same Barrier Property; Suitable For Both 85℃ Pasteurization And 121℃ High Temperature Stream Strralization.



Excellent Sealing Strength Through Contamination, Minimizing Leakers; Good Transparency And Gloss.




Our Advantage:



1.Excellent deep draw thermoforming over a wide range of draw ratios.



2.Excellrnt gas,water and vapour barrierr property.



3.Great forming uniformity, high-efficiency water blocking,keep food fresh for a long time.



4.Good puncture resistance and heat-sealing performance.



5.High transparency and great gloss,improve the brightness and saturation of the product packaging.





Product Features:



1, performance: CO extruded film, to achieve high barrier effect of oxygen, water, carbon dioxide, odor;



2, powerful: oil resistant, moisture resistant, resistant to 100 ° C high temperature cooking, low temperature freezing, quality preservation, smell. Can be used for vacuum packaging, aseptic packaging, inflatable packaging;



3, flexible structural design: different structural design can be used to meet the quality requirements of different products;



4, high strength: high tensile strength, good flexibility, good sealing;



5, small capacity: CO extruded film can be used for vacuum shrink packaging, volume and capacity ratio close to 100%, which is unmatched by glass, cans, paper packaging;





Our advantage:



1. Equipment:
We have the most advanced Germany W&H eleven-layer co-ectruded cast film production line.



2.Capacity Advantage:
Good equipment,extensive production experience,reasonable workshop planning,strong technique.



3. Materials:
All cast films are made of high-quality America and Japan import food grade raw materials.



4.Customer Maintenance:
One-to-one service,reply within 24 hours,communicate and visit exchange.



5. After Service:
We can prepare all documents you need, and solve all problems related to the current order.





Data Sheet:



Coex Casting Film
  Unit PA/PE PA/PP PA/EVOH/PE PA/EVOH/PP
Thickness um 80 90 175 90
Tensile MD/TD Mpa > 25 >25 > 25 ≥ 25
Strength
Elongation MD/TD % > 400 > 400 > 450 ≥ 380
Transparence % ≥ 93 ≥ 93 ≥ 92 ≥ 92
Haze % < 4 < 6 < 10 ≤ 6
Coefficient Of Friction IN/IN 0 .35 0.5 0.35 0.5
WTR g/sq.m/day < 8 < 8 < 3 ≤ 10
(38° C, 100%RH)
OTR cc/sq.m/day < 40 < 40 < 1 ≤ 5
(23 ° C 100%RH)
Sealing Strength N/15mm > 25 > 30 > 50 ≥ 25



--Multilayer film which are producedby combining different polymer layers , offer special attributes as barrier properties against oxygen,water vapour and aromas.
--Easy processing for automatic thermoforming machines.
--Absolutely no inherent curling of web.
--High transparency and high gloss.





Q&A:



Q1: Are you factory ?
A1: Yes,we have been in packaging industry for over 10 years from 2009.



Q2: What is yours main product?
A2: We are mainly produce 7/9/11 multi-layer co-extrusion cast barrier film and plastic packaging bags, Our material is PA,PE,PP,EVOH etc.



Q3: What's the minium quantity(MOQ)?
A3: 2 tons or 20000 pieces.



Q4: How long is shipping time?
A4: 15-20 Days after received payment





Samples can be provided for testing, but the MOQ for formal orders is 1-2 tons.





If you are interested in it, please feel free to contact me, tell me your needs, I will send you more product details, and I can quote you a good price.

MOQ: 1-2Ton. Please tell me the purchase details, I can help you calculate the specific quantity of MOQ PCS/Roll.
